Rack Mounted Block Converters with HIgh Performance Options

This equipment is designed for applications where frequency translation is needed between L-band and the transponder frequencies.

✓ Added to quote Download Specs

Product Features

Amplitude slope adjust
RS422, RS485 and 10/100Base-T Ethernet
Serial output for Redundancy Switchover units
RF and L-band monitor ports
Automatic 5/10 MHz internal/external reference selection
Electronic adjust of internal reference frequency
Low phase noise
Low intermodulation distortion
64 programmable memory locations
45 dB of independent RF and L-band level control
Mute function on alarm or external mute input command
Elapsed time and event log after power turn on
CE Mark

Options Available : See Spec Sheet

The GeoSync Guarantee

Our company strives to innovate and reinvent the marketplace with our flagship lineup of commercial and military SATCOM products. This same ingenuity is also ingrained in our customer relationship and support systems.

Available Models

Model	Frequency Range (GHz)
UBR-6.1-INV	5.85 – 6.425
UBR-6.25	5.85 – 6.65
UBR-6.28	5.85 – 6.725
UBR-6.9	6.7 – 7.1
UBR-8.15	7.9 – 8.4
UBR-12.25	11.7 - 12.75
UBR-13	12.75 – 13.25
UBR-14.125	13.75 – 14.5
UBR-14.25	14 – 14.5
UBR-17.7	17.3 – 18.1
UBR-17.85	17.3 – 18.4
UBR-18.25	18.1 – 18.4
DBR-3.8-INV	3.4 – 4.2
DBR-3.8	3.4 – 4.2
DBR-3.95	3.7 – 4.2
DBR-4.65	4.5 – 4.8
DBR-7.5	7.25 – 7.75
DBR-11.2	10.7 – 11.7
DBR-11.35	10.95 – 11.7
DBR-11.6	11.2 – 12
DBR-11.8	11.4 – 12.2
DBR-11.85	11.45 – 12.25
DBR-12.1	11.7 – 12.5
DBR-12.225	11.7 – 12.75
DBR-12.475	12.2 – 12.75
DBR-12.725	12.2 – 13.25
